26 September 1927

Flight Lieutenant Sidney N. Webster, RAF, leads the Schneider Trophy Race with his Supermarine S.5 N220. (Unattributed)
Flight Lieutenant Sidney N. Webster, RAF, leads the Schneider Trophy Race with the blue and silver Supermarine S.5 racer, N220. (Unattributed)
Flight Lieutenant Sidney Norman Webster, Royal Air Force.
Flying Officer Sidney Norman Webster, Royal Air Force, circa 1919. (Unattributed)

26 September 1927: Flight Lieutenant Sidney Norman Webster, A.F.C., of the Royal Air Force High-Speed Flight, won the 1927 Schneider Trophy Race, flying a Supermarine S.5 float plane, number N220.

The course consisted of seven laps of a 50-kilometer course at Venice, Italy. Webster completed the race in 46 minutes, 20.3 seconds, averaging 281.656 miles per hour (453.281 kilometers per hour). He established a new Fédération Aéronautique Internationale (FAI) World Record for Speed Over 100 Kilometers.¹

Webster’s teammate, Flight Lieutenant Oswald Worsley, flying S.5 N219, placed second with a time of 47:46.7 and average speed of 272.91 miles per hour (439.21 kilometers per hour).

With its engine running, this Supermarine S.5 shows off its very clean lines.

The Supermarine S.5 was designed by Reginald Mitchell, who would later design the famous Supermarine Spitfire fighter. N220 was a single-place, single-engine, low-wing monoplane equipped with pontoons for landing and taking off on water. The airplane was of all metal construction, primarily duralumin (a hardened alloy of aluminum and copper). The airplane used surface radiators in the skin of the wings for engine cooling.

The S.5 had a length of 24 feet, 3½ inches (7.404 meters), wingspan of 26 feet, 9 inches (8.153 meters) and height of 11 feet, 1 inch (3.378 meters). The S.5’s empty weight was 2,680 pounds (1,216 kilograms) and gross weight was 3,242 pounds (1,471 kiograms).

Supermarine S.5 N220 at Venice, Italy, September 1927. (FlightGlobal)
Supermarine S.5 N220 at Venice, Italy, September 1927. (FlightGlobal)

Webster’s Supermarine S.5 was powered by a water-cooled, naturally-aspirated 1,461.135-cubic-inch-displacement (23.943 liter) D. Napier and Son, Ltd., Lion Mk.VIIB, serial number 63106, a double-overhead camshaft (DOHC) twelve-cylinder engine with three banks of four cylinders. This was called a “Triple-Four,” “W-12,” or “broad arrow” configuration. The Napier Lion had an included angle of 60° between each cylinder bank.

D. Napier and Son, Ltd., Lion VII “broad arrow” 12-cylinder aircraft engine.

The Mk.VIIB had four valves per cylinder and a compression ratio of 10:1. It produced 875 horsepower at 3,300 r.p.m. The Lion VIIB drove a two-bladed fixed-pitch propeller through a gear reduction unit with a ratio of 0.765:1. (Worsley’s Supermarine S.5, N219, was equipped with a 900 horsepower direct-drive Mk.VIIA.) The engine used a mixture of 75% gasoline, 25% benzol, and 0.22% “T.E.L. dope” (tetraethyl lead) additive. The Napier Lion Mk.VII was 5 feet, 6¼ inches (1.683 meters) long, 3 feet, 2½ inches (0.978 meters) wide and 2 feet, 10½ inches (0.876 meters) high. The geared Mk.VIIB was heavier than the direct drive Mk.VIIA, and weighed 920 pounds (417 kilograms).

The Supermarine S.5 had a maximum speed of 319.57 miles per hour (514.3 kilometers per hour).

“Webbie” Webster had been awarded the Air Force Cross on 2 January 1922. He received a second award, signified by a “bar” added the the ribbon of his medal, 11 October 1927:

Air Ministry.

11th October, 1927.

     The KING has been graciously pleased to approve the award of a Bar to the Air Force Cross held by Flight Lieutenant Sidney Norman Webster, A.F.C., in recognition of his achievement winning the recent “Schneider Cup” Air Race.

Flight Lieutenant Sidney N. Webster, RAF, stands with his winning Supermarine S.5, N220, at the Woolston factory. Designer Reginald Mitchel is in the front row at center.
Flight Lieutenant Sidney N. Webster, RAF, stands with his winning Supermarine S.5, N220, at the Woolston factory. Designer Reginald Mitchell is in the front row at center.

In January 1946, Air Commodore Webster was appointed Commander of the Most Excellent Order of the British Empire. He was promoted to Air Vice Marshal in 1949 and retired from the Royal Air Force 12 August 1950.

Air Vice Marshal Sidney Norman Webster, C.B.E., A.F.C. and Bar, Royal Air Force, died 5 April 1984 at the age of 83 years.

Schneider trophy at the Science Museum, London. (Wikipedia)
Coupe d’Aviation Maritime Jacques Schneider (the Schneider Cup) at the Science Museum, London. (Wikipedia)

¹ FAI Record File Number 11070
