6 November 1958

Bell X-1E 46-063 on Rogers Dry Lake. (NASA)
Bell X-1E 46-063 on Rogers Dry Lake, 1955. (NASA)

6 November 1958: NASA Research Test Pilot John B. (Jack) McKay made the final flight of the X-1 rocketplane program, which had begun twelve years earlier.

Bell X-1E 46-063 made its 26th and final flight after being dropped from a Boeing B-29 Superfortress over Edwards Air Force Base on a flight to test a new rocket fuel.

John B. McKay, NACA/NASA Research Test Pilot. (NASA)
John B. McKay, NACA/NASA Research Test Pilot. (NASA)

When the aircraft was inspected after the flight, a crack was found in a structural bulkhead. A decision was made to retire the X-1E and the flight test program was ended.

The X-1E had been modified from the third XS-1, 46-063. It used a thinner wing and had an improved fuel system. The most obvious visible difference is the cockpit, which was changed to provide for an ejection seat. Hundreds of sensors were built into the aircraft’s surfaces to measure air pressure and temperature.

The Bell X-1E was 31 feet (9.449 meters) long, with a wingspan of 22 feet, 10 inches (6.960 meters). The rocketplane’s empty weight was 6,850 pounds (3,107 kilograms) and fully loaded, it weighed 14,750 pounds (6,690 kilograms). The rocketplane was powered by a Reaction Motors XLR11-RM-5 rocket engine which produced 6,000 pounds of thrust (26.689 kilonewtons). The engine burned ethyl alcohol and liquid oxygen. The X-1E carried enough propellants for 4 minutes, 45 seconds burn.

The Bell X-1E rocketplane being loaded into a Boeing B-29 Superfortress mothership for another test flight. (NASA)
The Bell X-1E rocketplane being loaded into NACA 800, a Boeing B-29-96-BW Superfortress mothership, 45-21800, for another test flight. (NASA)

The early aircraft, the XS-1 (later redesignated X-1), which U.S. Air Force test pilot Charles E. (“Chuck”) Yeager flew faster than sound on 14 October 1947, were intended to explore flight in the high subsonic and low supersonic range. There were three X-1 rocketplanes. Yeager’s Glamorous Glennis was 46-062. The X-1D (which was destroyed in an accidental explosion after a single glide flight) and the X-1E were built to investigate the effects of frictional aerodynamic heating in the higher supersonic ranges from Mach 1 to Mach 2.

Bell X-1E loaded aboard Boeing B-29 Superfortress, circa 1955. (NASA)
Bell X-1E 46-063 loaded aboard NACA 800, a Boeing B-29-96-BW Superfortress, 45-21800, circa 1955. (NASA)

The X-1E reached its fastest speed with NASA test pilot Joseph Albert Walker, at Mach 2.24 (1,450 miles per hour/2,334 kilometers per hour), 8 October 1957. Walker also flew it to its peak altitude, 70,046 feet (21,350 meters) on 14 May 1958.

NACA test pilot Joseph Albert Walker made 21 of the X-1E's 26 flights. In this photograph, Joe Walker is wearing a David Clark Co. T-1 capstan-type partial-pressure suit with a K-1 helmet for protection at high altitudes. (NASA)
NACA test pilot Joseph Albert Walker made 21 of the X-1E’s 26 flights. In this photograph, Joe Walker is wearing a David Clark Co. T-1 capstan-type partial-pressure suit with a K-1 helmet for protection at high altitudes. (NASA)

There were a total of 236 flights made by the X-1, X-1A, X-1B, X-1D and X-1E. The X-1 program was sponsored by the National Advisory Committee on Aeronautics, NACA, which became the National Aeronautics and Space Administration, NASA, on 29 June 1958.

The X-1E is on display in front of the NASA administration building at the Dryden Flight Research Center, Edwards Air Force Base, California.Bell X-1E 46-063 on display at Dryden Flight Research Center© 2016, Bryan R. Swopes

4 November 1941

Lockheed YP-38 Lightning 39-689, manufacturer's serial number 122-2202. (Lockheed)
Lockheed YP-38 Lightning 39-689, manufacturer’s serial number 122-2202. (Lockheed Martin)
Ralph Burwell. Virden (Los Angeles Times)

4 November 1941: Lockheed test pilot Ralph Burwell Virden was conducting high speed dive tests in the first Lockheed YP-38 Lightning, Air Corps serial number 39-689 (Lockheed’s serial number 122-2202).

As the airplane’s speed increased, it approached what is now known as its Critical Mach Number. Air flowing across the wings accelerated to transonic speeds and began to form shock waves. This interrupted lift and caused a portion of the wing to stall. Air no longer flowed smoothly along the airplane and the tail surfaces became ineffective. The YP-38 pitched down into a steeper dive and its speed increased even more.

Designed by famed aeronautical engineer Clarence L. “Kelly” Johnson, the YP-38 had servo tabs on the elevator that were intended to help the pilot maintain or regain control under these conditions. But they increased the elevator’s effectiveness too well.

The Los Angeles Times described the accident:

     Witnesses said the twin-engined, double-fuselaged ship was booming westward at near maximum speed (unofficially reported to be between 400 and 500 miles an hour) when the duralumin tail assembly “simply floated away.”

     A moment afterward the seven-ton craft seemed to put on a burst of speed, the the high whine of its engines rising.

     It then went into a downward glide to about 1500 feet, then into a flat spin, flipped over on its back and shot earthward.

     Several persons said that they thought they had heard an explosion during the dive, but qualified observers doubted it. . .

     . . . Fellow pilots at Lockheed said, “Ralph was the best we had, especially in power dives.”

      Robert E. Gross, president of Lockheed, said, “Ralph Virden was a great pilot but an even greater man. If anyone ever had national defense at heart it was he, who every day was carrying the science of aviation into new and higher fields.”

     Various witnesses said the ill-fated ship’s tail assembly could be followed easily as its bright surfaces glinted in the sun during its drop to earth. It landed several blocks from the scene of the crash.

     Mrs. Jack Davenport of 1334 Elm Ave., left her ironing board when she heard the unfamiliar roar of the plunging plane’s engines.

     “I ran out and saw it passing over us, very low. It disappeared among the trees and then zoomed back into sight just before crashing in the next block,” she said. “It looked just like a toy airplane. I knew the pilot didn’t have a chance, as the ship was too low and going too fast.”

Los Angeles Times, Vol. LX, Wednesday, 5 November 1941, Page 1, Column 6, and Page 2, Column 5.

The YP-38 crashed into the kitchen of Jack Jensen’s home at 1147 Elm Street, Glendale, California. Fire erupted. Ralph Virden was killed. The airplane’s tail section was located several blocks away.

Another view of Lockheed YP-38 Lightning 39-689. It's factory serial number, "2202," is stenciled on the nose. (Lockheed Martin)
Another photograph of Lockheed YP-38 Lightning 39-689. The factory serial number, “2202,” is stenciled on the nose. (Lockheed Martin)

39-689 was the first of thirteen YP-38 service test aircraft that had been ordered by the U.S. Army Air Corps shortly after the XP-38 prototype, 37-457, had crashed on a transcontinental speed record attempt, 11 February 1939. 39-689 made its first flight 16 September 1940 with test pilot Marshall Headle at the controls. With hundreds of production P-38s being built, Lockheed continued to use the YP-38 for testing.

Newspaper phototograph of the wreckage of Lockheed YP-38 Lightning 39-689 at 1147 Elm Street, Glendale, California. (Los Angeles Times)
Newspaper photograph of the wreckage of Lockheed YP-38 Lightning 39-689 at 1147 Elm Street, Glendale, California. (Los Angeles Times)

The YP-38s were service test prototypes of a single-place, twin engine long range fighter with a unique configuration. There was not a fuselage in the normal sense. The cockpit, nose landing gear, and armament were contained in a central nacelle mounted to the wing. Two engines and their turbochargers, cooling systems and main landing gear were in two parallel booms. The booms end with vertical fins and rudders, with the horizontal stabilizer and elevator between them. The P-38 was 37 feet, 9–15/16 inches (11.530 meters) long, with a wingspan of 52 feet, 0 inches (15.850 meters) and height of 12 feet, 10 inches (3.952 meters).

The P-38’s wings had a total area of 327.50 square feet (30.43 square meters). Their angle of incidence was 2° and there was 5° 40′ dihedral. The leading edges were swept aft 5° 10′.

The YP-38 had an empty weight 11,171 pounds (5,067 kilograms). The gross weight was 13,500 pounds (6,123 kilograms) and the maximum takeoff weight 14,348 pounds (6,508 kilograms).

The YP-38 was powered by two counter-rotating, liquid-cooled, turbosupercharged 1,710.597-cubic-inch displacement (28.032 liter) Allison V-1710-27 right-hand tractor and V-1710-29 left-hand tractor, single overhead cam (SOHC) 60° V-12 engines (Allison Engineering Co. Models F2R and F2L) with a Normal Power rating of 1,000 horsepower at 2,600 r.p.m., and 1,150 horsepower at 3,000 r.p.m. for takeoff. They drove three-bladed Curtiss Electric constant-speed propellers with a diameter of 11 feet, 6 inches (3.505 meters) through a 2.00:1 gear reduction. In a change from the XP-38, the propellers rotated outboard at the top of their arc. The V-1710-27/-29 engines were 7 feet, 1-5/8 inches (2.175 meters) long, 2 feet, 5-9/32 inches (0.744 meters) wide and 3 feet, 0-17/32 inches (0.928 meters) high. The V-1710-27/-29 weighed 1,305 pounds (592 kilograms)

The YP-38 had a maximum speed of 405 miles per hour (651.8 kilometers per hour) at 10,000 feet (3,048 meters) and it could climb  from the surface to 20,000 feet (6,096 meters) in six minutes. Normal range 650 miles (1,046 kilometers).

Lockheed built one XP-38, thirteen YP-38s, and more than 10,000 production fighter and reconnaissance airplanes. At the end of World War II, orders for nearly 2,000 more P-38 Lightnings were cancelled.

Lockheed YP-38 39-692 in flight.(Hans Groenhoff Photographic Collection, Smithsonian Institution National Air and Space Museum NASM-HGC-967)

Ralph Burwell Virden was born 11 June 1898, at Audobon Township, Illinois. He was the second child of Hiram R. Virden, a farmer, and Nancy Carrie Ivy Virden.

Virden attended Bradley Polytechnic Institute at Peoria, Illinois. At the age of 17, 15 October 1918, Ralph Virden enlisted in the U.S. Army. With the end of World War I less than one month later, he was quickly discharged, 7 December 1918.

In 1919, Ralph Virden married Miss Florence I. McCullers. They would have two children, Kathryn and Ralph, Jr. Kathryn died in 1930 at the age of ten years.

Ralph Burwell Virden with a Boeing Model 40 mail plane, circa late 1920s. As a U.S. Air Mail pilot, Virden is armed with a .45-caliber Colt M1911 semi-automatic pistol. (San Diego Air and Space Museum Archives)
Boeing Airplane Company President Clairmont L. Egvtedt and United Air Lines Captain Ralph B. Virden examine a scale model of the Boeing 247D airliner. (Boeing)

During the mid-1920s, Virden flew as a contract mail pilot. He held Airline Transport Pilot Certificate No. 628, and was employed by Gilmore Aviation and Pacific Air Transport. For thirteen years, Virden was a pilot for United Air Lines. He joined Lockheed Aircraft Company as a test pilot in 1939. He had flown more than 15,000 hours.

Virden lived at 4511 Ben Ave., North Hollywood, California, with his  family. Ralph, Jr., now 19 years of age, was also employed at Lockheed. (Following his father’s death, the younger Virden enlisted in the United States Navy.)

After the accident, Lockheed, the Air Corps and the National Advisory Committee on Aeronautics (NACA) undertook an extensive test program of the P-38.

The Lockheed YP-38 Lightning, 39-690, was sent to the NACA Research Center at Langley Field, Virginia. This photograph is dated 4 February 1942. (NASA)
The second Lockheed YP-38 Lightning, 39-690, was sent to the NACA Langley Research Center at Langley Field, Virginia. This photograph is dated 4 February 1942. (NASA)
Lockheed YP-38 39-690 in the NACA Full Scale Tunnel, December 1944. (NASA)
Lockheed YP-38 39-690 in the NACA Full Scale Tunnel, December 1944. (NASA)
Lockheed YP-38 Lightning 39-690, serial number 122-2203. (NASA)
Lockheed YP-38 Lightning 39-690, serial number 122-2203. (NASA)
Lockheed YP-38 #2 in the NACA full-scale wind tunnel at Langley, Virginia. (NASA)
Lockheed YP-38 Lightning, 39-690 (122-2203), in the NACA Langley Research Center’s full-scale wind tunnel at Langley Field, Virginia, December 1944. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690. (NASA)
Lockheed YP-38 Lightning 39-690, 122-2203. (NASA)
Lockheed YP-38 Lightning 39-690, 122-2203. (NASA)

© 2018, Bryan R. Swopes

27 October 1954

NACA's chief project test pilot for the Douglas X-3, in the cockpit of the research aircraft, circa 1954-1956. (LIFE Magazine via Jet Pilot Overseas)
NACA’s chief project test pilot for the Douglas X-3, Joe Walker, in the cockpit of the research aircraft, circa 1954-1956. (LIFE Magazine via Jet Pilot Overseas)

October 27, 1954: Between August 1954 and May 1956, Joseph A. Walker, the National Advisory Committee for Aeronautics’ chief project test pilot for the Douglas X-3 supersonic research aircraft, made twenty research flights in the “Stiletto.”

On the tenth flight, 27 October, Walker took the X-3 to an altitude of 30,000 feet (9,144 meters). With the rudder centered, he put the X-3 into abrupt left aileron rolls, first at 0.92 Mach and then at Mach 1.05. Both times, the aircraft violently yawed to the right and then pitched down. Walker was able to recover before the X-3 was completely out of control.

Screen Shot 2015-10-20 at 12.08.52
The Douglas X-3 during NACA flight testing, 1954-1956. (LIFE Magazine via Jet Pilot Overseas)

This was a new and little understood condition called inertial roll coupling. It was a result of the aircraft’s mass being concentrated within its fuselage, the gyroscopic effect of the turbojet engines and the inability of the wings and control surfaces to stabilize the airplane and overcome its rolling tendency. (Just two weeks earlier, North American Aviation’s Chief Test Pilot George S. Welch had been killed when the F-100A Super Sabre that he was testing also encountered inertial roll coupling and disintegrated.)

A post-flight inspection found that the X-3 had reached its maximum design load. The airplane was grounded for the next 11 months.

Unlike its predecessors, the Bell Aircraft Corporation's X1 and and X-2 rocketplanes, teh turbojet-powered Douglas X-3 took off under its own power. here, its two Westinghouse J37 engines are stirring up teh sand on Runway 35 at Rogers Dry Lake. (LIFE Magazine via jet Pilot Overseas)
Unlike its predecessors, the Bell Aircraft Corporation’s X1 and and X-2 rocketplanes, the turbojet-powered Douglas X-3 took off under its own power. Here, its two Westinghouse J37 engines are stirring up the sand on Runway 35 at Rogers Dry Lake. (LIFE Magazine via jet Pilot Overseas)

The Douglas X-3, serial number 49-2892, was built for the Air Force and NACA to explore flight in the Mach 1 to Mach 2 range. It was radically shaped, with a needle-sharp nose, very long thin fuselage and small straight wings. Two X-3 aircraft had been ordered from Douglas, but only one completed.

The X-3 was 66 feet, 9 inches (20.345 meters) long, with a wing span of just 22 feet, 8.25 inches (6.915 meters). The overall height was 12 feet, 6.3 inches (3.818 meters). The X-3 had an empty weight of 16,120 pounds (7,312 kilograms) and maximum takeoff weight of 23,840 pounds (10,814 kilograms).

It was to have been powered by two Westinghouse J46 engines, but when those were unsatisfactory, two Westinghouse XJ34-WE-17 engines were substituted. This was an axial flow turbojet with an 11-stage compressor and 2-stage turbine. It was rated at 3,370 pounds (14.99 kilonewtons) of thrust, and 4,900 pounds (21.80 kilonewtons) with afterburner. The XJ34-WE-17 was 14 feet, 9.0 inches (4.496 meters) long, 2 feet, 1.0 inch (0.635 meters) in diameter and weighed 1,698 pounds (770 kilograms).

The X-3 had a maximum speed of 706 miles per hour (1,136 kilometers per hour) and a service ceiling of 38,000 feet (11,582 meters).

The X-3 was very underpowered with the J37 engines, and could just reach Mach 1 in a shallow dive. The X-3′s highest speed, Mach 1.208, required a 30° dive. It was therefore never able to be used in flight testing the supersonic speed range for which it was designed. Because of its design characteristics, though, it was very useful in exploring stability and control in the transonic range.

At one point, replacing the X-3’s turbojet engines with two Reaction Motors XLR-11 rocket engines was considered. Predictions were that a rocket-powered X-3 could reach Mach 4.2. However, with Mach 2 Lockheed F-104 becoming operational and North American Aviation’s X-15 hypersonic research rocketplane under construction, the idea was dropped. Technology had passed the X-3 by.

In addition to Douglas Aircraft test pilot Bill Bridgeman, the Douglas X-3 was flown by Air Force test pilots Lieutenant Colonel Frank Everest and Major Chuck Yeager and  NACA pilot Joe Walker.

Joe Walker resumed flight testing the X-3 in 1955. Its final flight was 23 May 1956. After the flight test program came to an end, the X-3 was turned over to the National Museum of the United States Air Force, Wright-Patterson Air Force Base, Ohio.

NACA test pilot Joe Walker with the Douglas X-3. (LIFE Magazine via Jet Pilot Overseas)
NACA test pilot Joe Walker with the Douglas X-3. (LIFE Magazine via Jet Pilot Overseas)

© 2018, Bryan R. Swopes

14 October 1938

The Curtiss-Wright XP-40 prototype, 38-10, on its first flight, 14 October 1938. Test pilot Ed Elliot is in the cockpit. (San Diego Air and Space Museum Archives) 16_008532

14 October 1938: At Buffalo, New York, test pilot Everett Edward Elliot made the first flight in the new Curtiss-Wright Corporation’s Model 75P, a prototype for a single-engine pursuit plane which had been designated XP-40 by the U.S. Army Air Corps.

Curtiss-Wright’s Chief Engineer, Donovan Reese Berlin, had taken the tenth production P-36A Hawk, Air Corps serial number 38-10, and had its air-cooled radial engine replaced with the Harold Caminez-designed, liquid-cooled, supercharged, 1,710.597-cubic-inch-displacement (28.032 liter) Allison Engineering Co. V-1710-C13 (V-1710-19).

Donovan Reese Berlin. (Niagara Aerospace Museum)

The V-1710-19 was a single overhead cam (SOHC) 60° V-12 engine with four valves per cylinder and a compression ration of 6.65:1. It had a Normal Power rating of 910 horsepower at 2,600 r.p.m. at Sea Level, and 1,060 horsepower at 2,950 r.p.m. for Takeoff. At 10,000 feet (3,048 meters), the V-1710-19 had Maximum Continuous Power rating of 1,000 horsepower at 2,600 r.p.m., and Military Power rating of 1,150 horsepower at 2,950 r.p.m. The engine required 100/130-octane aviation gasoline. It drove a three-bladed Curtiss Electric constant-speed propeller through a 2:1 gear reduction. The V-1710-19 was 8 feet, 1.75 inches (2.483 meters) long, 3 feet, 4.75 inches (1.035 meters) high and 2 feet, 4.94 inches (0.735 meters) wide. It weighed 1,320 pounds (599 kilograms).

Curtiss-Wright XP-40 38-10 (SDASM 16_008531)

At 1,829.39-cubic-inches (29.978 liters), the original Pratt & Whitney Twin Wasp S1C1-G (R-1830-17) 14-cylinder radial engine had greater displacement and produced 80 horsepower more for takeoff than the Allison V-12. The long, narrow V-12, though, allowed for a much more streamlined engine cowling for higher speed and greater efficiency.

XP-40 16_008533
Curtiss-Wright XP-40 prototype. (SDASM 16_008534)
The Curtiss XP-40 prototype at Langley Field in the original configuration. (NASA)
The Curtiss-Wright XP-40 in the original configuration at Langley Field. (NASA)
Everett Edward Elliot (1907–1981).

In the early testing, the XP-40 was much slower than expected, reaching only 315 miles per hour (507 kilometers per hour). (The P-36A Hawk had a maximum speed of  313 miles per hour). Engineers experimented with different placement for the coolant radiator, oil coolers and the engine air intake. The Air Corps project officer, Lieutenant Benjamin Scovill Kelsey, had the prototype sent to the National Advisory Committee for Aeronautics (NACA) Research Center at Langley Field, Virginia, where the full-size airplane was placed inside a wind tunnel.

Over a two-month period, NACA engineers made a number of improvements. The radiator was moved forward under the engine and the oil coolers utilized the same air scoop. The exhaust manifolds were improved as were the landing gear doors.

When they had finished, Lieutenant Kelsey flew the modified XP-40 back to Curtiss. Its speed had been increased to 354 miles per hour (570 kilometers per hour), a 12% improvement.

By December 1939 the airplane had been further improved and was capable of 366 miles per hour (589 kilometers per hour).

The Curtiss-Wright XP-40 prototype in a wind tunnel at Langley Field, 24 April 1939. (NASA)
Curtiss XP-40 in the NACA Full Scale Wind Tunnel at Langley Field, Virginia, April 1939. (NASA)
Curtiss-Wright XP-40 in the NACA Full Scale Wind Tunnel at Langley Field, Virginia, 24 April 1939. (NASA)

The Curtiss Hawk 75P, XP-40 38-10, was 31 feet, 1 inch (9.574 meters) long with a wingspan of 37 feet, 4 inches (11.354 meters) and overall height of 12 feet, 4 inches (3.734 meters). It had an empty weight of 5,417 pounds (2,457.1 kilograms) and maximum gross weight of 6,870 pounds (3,116.2 kilograms).

The prototype had a maximum speed of 342 miles per hour (550 kilometers per hour) at 12,200 feet (3,719 meters) with a gross weight of 6,260 pounds (2,839.5 kilograms). Its range was 460 miles (740 kilometers) flying at 299 miles per hour (481 kilometers per hour) with 100 gallons (378.5 liters) of fuel. With 159 gallons (601.9 liters) and with speed reduced to 200 miles per hour (322 kilometers per hour), the XP-40 had a maximum range of 1,180 miles (1,899 kilometers).

The prototype was armed with two air-cooled Browning AN-M2 .50-caliber machine guns mounted above the engine and synchronized to fire forward through the propeller arc.

The Air Corps placed an initial order for 524 P-40s. This was the largest single order for airplanes by the U.S. military up to that time. The first production model was the P-40 Warhawk, armed with two .50-caliber machine guns. There was only one P-40A variant which was a P-40 modified as a camera aircraft. The definitive pursuit model was the P-40B Warhawk, which retained the two .50-caliber guns of the P-40 and added two Browning M2 .30-caliber machine guns to each of the wings.

A Curtiss-Wright P-40B Warhawk, 79th Pursuit Squadron, 20th Pursuit Group, Hamilton Field, California, 1940. (U.S. Air Force)

The P-40B was best known as the airplane flown by the American Volunteer Group fighting for China against the Japanese. They were called the “Flying Tigers”. Between 1939 and 1945, Curtiss built 13,738 P-40s in many configurations. They flew in combat in every theater of operations during World War II.

A Curtiss-Wright Hawk 81-A3 (Tomahawk IIb) of the American Volunteer Group, Kunming, China, 1942. (U.S. Air Force)

© 2018, Bryan R. Swopes

8 October 1954

Captain Arthur W. Murray, U.S. Air Force (1918–2011). Murray is wearing a David Clark Co. T-1 capstan-type partial-pressure suit with K-1 helmet for high altitude flight. (U.S. Air Force)
Captain Arthur W. Murray, U.S. Air Force (1918–2011). Murray is wearing a David Clark Co. T-1 capstan-type partial-pressure suit. (U.S. Air Force)

8 October 1954: After two earlier glide flights flown by test pilot Jack Ridley, Captain Arthur Warren (“Kit”) Murray, U.S. Air Force, made the first powered flight of the Bell Aircraft Corporation X-1B rocket-powered supersonic research aircraft, serial number 48-1385.

Five months earlier, Murray had flown the X-1A to an altitude of 90,440 feet (25,570 meters). He was the first pilot to fly high enough to see the curvature of the Earth and a dark sky at mid day.

The X-1B was the third in a series of experimental X-1 rocketplane variants built by the Bell Aircraft Corporation for the United States Air Force and the National Advisory Committee for Aeronautics (NACA), for research into supersonic flight. It was fitted with 300 thermocouples to measure aerodynamic heating. It was the first aircraft equipped with a pilot-controlled reaction control system which allowed for maneuvering the aircraft at high altitudes where normal aerodynamic controls were no longer effective.

NACA 800, a modified Boeing B-29 Superfortress, 45-21800, with the Bell X-1B, at Edwards Air Force Base, 8 April 1958. (NASA)
NACA 800, a modified Boeing B-29 Superfortress, 45-21800, with the Bell X-1B, at Edwards Air Force Base, 9 April 1958. (NASA)

Like the X-1 and X-1A, the X-1B was carried by a modified four-engine B-29 Superfortress heavy bomber (B-29-96-BW 45-21800), before being airdropped at altitudes of 25,000 to 35,000 feet (7,620 to 10,668 meters) near Edwards Air Force Base, California. After its fuel was expended, the pilot would glide for a landing on Rogers Dry Lake.

The X-1B was 35 feet, 7 inches (10.846 meters) long with a wing span of 28 feet (8.53 meters). Its loaded weight was 16,590 pounds (7,520 kilograms). The X-1B was powered by a Reaction Motors XLR11-RM-6 four-chamber rocket engine, fueled with a mixture of water and alcohol with liquid oxygen. It produced 6,000 pounds of thrust (26.689 kilonewtons. The XLR11 was 5 feet, 0 inches (1.524 meters) long, 1 foot, 7 inches (0.483 meters) in diameter, and weighed 210 pounds (95 kilograms). Each of the four thrust chambers were 1 foot, 9¾ inches (0.552 meters) long and 6 inches (0.152 meters) in diameter.

The rocket plane was designed to reach 1,650 miles per hour (2,655 kilometers per hour) and 90,000 feet (27,432 meters).

Bell X-1B (Bell Aircraft Corporation)
Bell X-1B 46-1385 (U.S. Air Force)
Bell X-1B 46-1385 on Rogers Dry Lake (NASA E-2547)
Bell X-1B on Rogers Dry Lake (NASA)
Bell X-1B 46-1385 on Rogers Dry Lake (NASA)

This was Kit Murray’s only flight in the X-1B. After being flown by a number of other Air Force test pilots, including Stuart Childs and Frank Everest, the rocketplane was turned over to NACA for the continued flight test program. NACA research pilots John McKay and Neil Armstrong made those flights.

X-1B 48-1385 made 27 flights. It was retired in January 1958. It is in the collection of the National Museum of the United States Air Force at Wright-Patterson Air Force Base, Ohio.

Bell X-1B 46-1385 parked on Rogers Dry Lake, 30 July 1958. (NASA)
Bell X-1B 46-1385 parked on Rogers Dry Lake, 30 July 1958. (NASA)
Bell X-1B 46-1385 parked on Rogers Dry Lake, 30 July 1958. (NASA)
Bell X-1B 46-1385 parked on Rogers Dry Lake, 30 July 1958. (NASA)

Arthur Warren Murray was born at Cresson, Cambria County, Pennsylvania, 26 December 1918. He was the first of two children of Charles Chester Murray, a clerk, and Elsie Espy Murray.

Arthur Murray attended Huntingdon High School, Huntingdon, Pennsylvania, graduating 4 June 1936, and then studied Juniata College, also in Huntingdon, 1937–1938.

Kit Murray enlisted in the Field Artillery, Pennsylvania National Guard, 17 November 1939. (Some sources state that he served in the U.S. Cavalry.) Murray had brown hair and blue eyes, was 5 feet, 10 inches (1.78 meters) tall and weighed 150 pounds (68 kilograms). Following the United States’ entry into World War II, Sergeant Murray requested to be trained as a pilot. He was appointed a flight officer (a warrant officer rank), Army of the United States, on 5 December 1942. On 15 October 1943 Flight Officer Murray received a battlefield promotion to the commissioned rank of second lieutenant, A.U.S.

Between 6 January and 22 October 1943, Murray flew over 50 combat missions in the Curtiss-Wright P-40 Warhawk across North Africa. After about ten months in the Mediterranean Theater, he returned to the United States, assigned as an instructor flying the Republic P-47 Thunderbolt fighter bomber, stationed at Bradley Field, Hartford, Connecticut.

Lieutenant Murray married Miss Elizabeth Anne Strelic, who had immigrated from Czechoslovakia with her family as an infant, at Atlantic City, New Jersey, 29 December 1943. They would have six children, and foster a seventh. They later divorced. (Mrs. Murray died in 1980.)

Murray was promoted to 1st lieutenant, A.U.S., 8 August 1944. His next assignment was as a maintenance officer. He was sent to Maintenance Engineering School at Chanute Field, Rantoul, Illinois, and from there to the Flight Test School at Wright Field, Dayton, Ohio.

Murray was the first test pilot to be permanently assigned to Muroc Army Air Field (later, Edwards Air Force Base). Other test pilots, such as Captain Chuck Yeager, were assigned to Wright Field and traveled to Muroc as necessary.

Murray’s A.U.S. commission was converted to first lieutenant, Air Corps, United States Army, on 19 June 1947, with date of rank retroactive to 15 October 1946. The U.S. Air Force became a separate military service in 1947, and Lieutenant Murray became an officer in the new service.

Colonel Arthur Warren (“Kit”) Murray, U.S. Air Force.

Later, 1958–1960, Major Murray was the U.S. Air Force project officer for the North American Aviation X-15 hypersonic research rocketplane at Wright Field.

Colonel Murray retired from the U.S. Air Force in 1961. He next worked for Boeing in Seattle, Washington, from 1961 to 1969, and then Bell Helicopter in Texas.

On 4 April 1975, Kit Murray married his second wife, Ms. Ann Tackitt Humphreys, an interior decorator, in Tarrant County, Texas.

Colonel Arthur Warren Murray, United States Air Force (Retired), died at West, Texas, 25 July 2011, at the age of 92 years.
